YT24 Rock Drill
    Drilling Depth: 5M
    Drill Rod: B22
    Weight: 24Kg
Back to list

YT24 rock drill, pneumatic jack hammer can be used to digging dry or wet by horizontal holes, vertical holes or angling holes on medium-hard rock or hard rock. Widely used in mines, railway, irrigation and quarry to drill holes and for the second digging holes.

TypeYT24
Weight (kg)24
Air consumption (L/s)≤67
Bore Dia. (mm)Φ34-42
Drilling depth (m)5
Shank(mm)22×108
Air pressure (MPa)0.63
Suitable air-legsFT140BD
Height (kg)15.613.9
Length (mm)16871400
Feed length (mm)1250965
+8615063722570
All products are guaranteed for 12 months!
