HW-1500 Diamond Core Drill
-
Drilling depth: 400-1500 (m)
Related Power: 132 (KW)
Drill Diameter: 50-114 (mm)
HW-1500 diamond core drill utilizes an advanced load sensing control system within it’s hydraulic system, which is currently being adopted by the major international producers. The rig features quality pedrail tracks that provides the rig with strong climbing capabilities that enhances it’s capabilities even in the toughest terrain.
This drill rig is suited for the following drilling applications: Diamond core drilling; Directional drilling; Reverse circulation continuous coring; Percussion rotary ; Geo-tech; Water bores; Anchorage.
Parameter:
| Model | HW-1500 |
| Drilling depth | 400-1500 (M) |
| Related Power | 132(KW) |
| Drill Diameter | 50-114(mm) |
| Main Pump Pressure | 127(mpa) |
| Chuck Mode | Hydraulic |
| Clamp | Hydraulic |
| Weight | 10.6(T) |
